BQ Impregnated Diamond Core Bit
video

BQ Impregnated Diamond Core Bit

Product Description Impregnated diamond core bits are extensively utilized in cutting medium to extra hard formations. These bits are composed of high-quality synthetic diamond grits that are evenly mixed within a metal matrix. To boost their strength, they are further reinforced with cemented...
Send Inquiry
Chat Now

Description

Technical Parameters

Product Description

Impregnated diamond core bits are extensively utilized in cutting medium to extra hard formations. These bits are composed of high-quality synthetic diamond grits that are evenly mixed within a metal matrix. To boost their strength, they are further reinforced with cemented carbide and diamond materials.
These bits are specifically designed to handle various types of ground surfaces, ranging from crushed and highly abrasive terrain to fine-grained, consolidated, and super-hard rocks. Impregnated diamond bits serve as efficient grinding machines, where diamonds are embedded in an infiltrated or sintered matrix.
One remarkable feature of these bits is their ability to adapt as the diamonds wear and round. The matrix surrounding the diamonds erodes evenly, ensuring that sharp diamonds are continuously exposed. This perpetual exposure enables the bits to effortlessly cut through the rocky surface, maintaining their cutting effectiveness.
Overall, impregnated diamond core bits are an exceptional choice when it comes to tackling challenging formations and achieving efficient rock cutting results.

BQ Impregnated Diamond Bit


Basic Info

Product Name

BQ Impregnated Diamond Core Drill Bit

Brand

Zhongjin

Size

Outside diameter: 59.56mm ; inner diameter: 36.4mm

Application

Coalfield mining, geological exploration, water well drilling, water conservancy and hydropower, and wireline core barrel parts are some of the essential components involved in various industries. These sectors greatly rely on geological exploration to identify the presence of mineral resources, particularly in coalfields. Through the process of coalfield mining, these resources can be extracted for different purposes such as energy production and manufacturing.
Furthermore, water well drilling plays a crucial role in ensuring access to clean water sources, particularly in remote locations where water scarcity is a challenge. It involves the use of drilling techniques and equipment to penetrate the ground and access underground water reservoirs.
In addition to this, water conservancy and hydropower systems are essential for managing water resources and producing renewable energy. These systems help in the efficient utilization of water for irrigation, flood control, and power generation.
Lastly, wireline core barrel parts are used in the mining and drilling industry to retrieve intact rock samples from deep underground. These samples provide valuable information about the geological formations and help in assessing the feasibility of various projects.
Overall, these industries and components play a significant role in the development of infrastructure, energy production, and resource utilization. They contribute to the growth and sustainability of various sectors by ensuring the efficient exploration and extraction of resources while also promoting the conservation and management of water resources.

Applicable Strata

Sandsone, shale, limestone, conglomerate, marble, and similar rocks are categorized as soft to medium-hard rocks with a maximum hardness level of 12. Let's explore the properties and characteristics of these rocks.

Original

Wuxi, China

Certification

ISO9001

Price

Negotiable

Payment Term

TT, LC

Delivery Date

Negotiable

Packing

Export standard

Standard

DCDMA

MOQ

1 PCS

Please be informed that in addition to the BQ impregnated diamond core bit, there is a wide range of other BQ products available as well.

BQ Impregnated Diamond Core Drill Bit


Size of Diamond Core Bits and Reaming Shells

Model

Outside Diameter of Core Bit

Inside Diameter of Core Bit

Outside Diameter of Reaming shell

Inches

mm

Inches

mm

Inches

mm

BTW

2.345

59.56

1.667

42.1

2.36

59.95

NTW

2.965

75.31

2.218

56.1

2.98

75.7

HTW

3.762

95.57

2.809

71.1

3.783

96.09

AQ

1.875

47.63

1.062

26.97

1.89

48.01

BQ

2.345

59.56

1.433

36.4

2.36

59.95

BQ3

2.345

59.56

1.32

33.53

2.36

59.95

NQ

2.965

75.31

1.875

47.63

2.98

75.7

NQ3

2.965

75.31

1.775

45.08

2.98

75.7

HQ

3.762

95.57

2.5

63.5

3.783

96.09

HQ3

3.762

95.57

2.406

61.11

3.783

96.09

PQ

4.805

122.05

3.345

84.96

4.828

122.65

PQ3

4.805

122.05

3.27

83.06

4.828

122.65

T2-56

2.205

56

1.642

41.7

2.224

56.5

T2-76

2.992

76

2.429

61.7

3.019

76.5

T2-86

3.385

86

2.823

71.7

3.406

86.5

T2-101

3.976

101

3.295

83.7

3.996

101.5

T6-101

3.976

101

3.11

79

3.996

101.5

T6-131

5.157

131

4.252

108

5.157

131.5


Select Reference Table of Diamond Core Bits

Specificxations of Diamond Core Bits


Diamond Core Bits Crown Shapes

Diamond Core Bits Crown Shapes
